60W CXA CXB2530 High Bay Led Light Fixtures for Supermarket
Lighting
Quick Detail:
1. Dimension: Dia 78mm Height 35mm
2. Beam Angle: 90degree
3. Match Led: 10-100w LEDs
4. Materials : Borosilicate glass
5. Accessories: Metal holder, silicon gasket
6. Chips Package size < 53mm
7. Application: Led high bay light, Flood light, Flashing light,
Led Spot Light
Specifications:
| Product Name | 60W CXA CXB2530 High Bay Led Light Fixtures for Supermarket
Lighting |
| Model No | SOE-HB78-90 |
| Main parts | Optical glass Lens+silicone gasket+metal holder+Multichip
LED+Driver |
| Lens Material | Borosilicate Glass |
| MOQ | 10pcs |
| Lens size | Diameter 78mm, Height 35mm |
| Sample | 3 days |
| Delivery | 7-9 days |
| Certificate | ROHS, SGS |
| Quality guarantee | If you receive defective items, please email us a picture of the
defective part. We will send you replacement without extra charger,
or offer refund. |
| Main market | Europe, South America,North America, Asia |
Please use some soft paper or pure water to clear the lens;
Don't use any industrial solvent to clean the lens surface, such as
alcohol;
Storage Environment: Temperature 0-40°C, Humidity 30%-95%
Material Details:
Optical Grade High Borosilicate Glass 3.3
Abbe number : 65
Light transmittance (2mm): 92%
High hardness
Never get yellow comparing with PMMA material
Refractive index : 1.474
Thermal expansivity : (3.3 ± 0.1)×10-6/K
Heat resistant : working at -50~550 °C
Density (20 °C) : 2.23 gcm-1
90degree Led Glass Lens Drawing:
Led Glass Lens Distribution:
Related Glass lens:
| Model No. | Lens angle | Lens Dimensions | Match Led |
SOE-HB50-40
| 40° | D50mm*H28mm | 10-100W |
SOE-HB50-90
| 90° | D50mm*H24mm | 10-100W |
SOE-HB60-35
| 35° | D66mm*H48mm | 10-100W |
SOE-HB60-60
| 60° | D66mm*H34mm | 10-100W |
SOE-HB60-90
| 90° | D66mm*H17mm | 10-100W |
SOE-HB78-45
| 45° | D78mm*H44mm | 10-100W |
SOE-HB78-60
| 60° | D78mm*H40mm | 50-200W |
SOE-HB78-90
| 90° | D78mm*H35mm | 50-200W |
SOE-HB78-120
| 120° | D78mm*H26mm | 50-200W |
SOE-HB100-60
| 60° | D100mm*H39mm | 50-200W |
SOE-HB100-90
| 90° | D100mm*H35mm | 50-200W |
SOE-HB100-120
| 120° | D100mm*H33mm | 50-200W |
SOE-HB109-120
| 120° | D109mm*H33mm | 50-200W |
SOE-HB130-110
| 110° | D130mm*H35mm | 50-300W |
Advantages of glass optical lens led street light retrofit kits:
1. One-Stop Service of led street light components and 6 years
specializing in Led lens industry
2. Complete supplying system with full range of Products , from
high power leds ,led optical lens ,led constant drivers ,MCPCB
modules and many led light components
3. Strict process and quality control
4. Strong design and production capability
Led glass lens Applications:
It is used for High bay and low bay lighting , Applicate for Industrial
factory, warehouse, stadium, hypermarket, supermarket and other
indoor environments.
